ADSL Compliance
• Compliant with ADSL Standard
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.lite (ITU G.992.2)
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
• Compliant with ADSL2 Standard
- G.dmt.bis (ITU G.992.3)
- ADSL2 Annex M (ITU G.992.3 Annex M)
(Available for BiPAC 5200(S)A model only)
• Compliant with ADSL2+ Standard
- G.dmt.bisplus (ITU G.992.5)
- ADSL2+ Annex M (ITU G.992.5 Annex M)
(Available for BiPAC 7300(G)A model only)
Network Protocols and Features
• NAT, static routing and RIP-1/2
• Universal Plug and Play (UPnP) Compliant
• Dynamic Domain Name System (DDNS)
• Virtual Server and DMZ
• SNTP, DNS relay and IGMP proxy

Firewall & Virtual Private Network (VPN)
• Built-in NAT Firewall
• Stateful Packet Inspection (SPI)
• Prevent DoS attacks including IP Spoofing, Land Attack, Smurf
Attack, Ping of Death, TCP SYN Flooding, etc
• Packet Filtering - port, source IP address, destination IP address,
MAC address
• URL Content Filtering - string or domain name
• Password protection for system management
• VPN pass-through
Quality of Service Control
• Supports the DiffServ approach
• Traffic prioritization and bandwidth management based-on IP protocol, port number and address
Wireless 802.11g (BiPAC 7300G)
• Compliant with IEEE 802.11g and 802.11b standards
• 2.4 GHz - 2.484G Hz frequency range
• Up to 54 Mbps wireless operation rate
• 64/128 bits WEP supported for encryption
• Wireless Security with WPA-PSK/WPA2-PSK support
• WDS repeater function support
IPTV Application*
• IGMP Snooping
• Virtual LAN (VLAN)
• Quality of Service (QoS)
ATM and PPP Protocols
• ATM Adaptation Layer Type 5 (AAL5)
• Multiple Protocol over AAL5 (RFC 2684, formerly RFC 1483)
• Bridged or routed Ethernet encapsulation
• VC and LLC based multiplexing
• PPP over Ethernet (PPPoE)
• PPP over ATM (RFC 2364)
• OAM F4/F5
Management
• Quick Installation Wizard and Auto-scan ADSL settings
• Web-based GUI for remote and local management
• Firmware upgrade an
Web-based GUI
• Embedded Telnet server for remote and local management
• Available Syslog monitoring
• Supports DHCP server/client/relay • SNMP v3, MIB-I and MIB-II support
Operating Environment
• Operating temperature: 0 ~ 40ºC
• Storage temperature: -20 ~ 70ºC
• Humidity: 20 ~ 95% non-condensing
Models & Standards Support
• BiPAC 7300(G)A: Annex A & Annex M
• BiPAC 7300(G)B: Annex B
• BiPAC 7300(G)U: U-R2
• Annex A and Annex M: ADSL over POTS
• Annex B and Annex U-R2: ADSL over ISDN
Hardware Specification
Physical Interface(BiPAC 7300G)
• WLAN: fixed antenna
• LINE: ADSL port
• LAN: 4-port 10/100M auto-crossover (MDI/MDI-X) switch
• Factory default reset button
• Power jack
• Power switch
Physical Specification
• Dimensions: 5.20" x 3.70" x 1.38”(132mm x 94mm x 35mm)
Power Requirement
• Input: 12V DC, 1A
|
