Standards
• IEEE 802.3 10Base-T
• IEEE 802.3u 100Base-TX
• IEEE 802.3ab 1000Base-T
• IEEE 802.3z 1000Base-SX / LX
Network Protocols and Features
• NAT, static routing and RIP-1 / 2
• Universal Plug and Play (UPnP) Compliant
• Dynamic Domain Name System (DDNS)
• Virtual Server and DMZ
• SNTP, DNS relay and IGMP proxy
• IGMP snooping for video service
Firewall
• Built-in NAT Firewall
• Stateful Packet Inspection (SPI)
• Prevents DoS attacks including Land Attack, Ping of Death, etc.
• Remote access control for web base access
• Packet filtering
• Password protection for system management
• VPN pass-through
Quality of Service Control
• Supports the DiffServ approach
• Traffic prioritization and bandwidth management based-on IP protocol, port number and address
PPP Protocols
• PPP over Ethernet (PPPoE)
IPTV Applications*1
• IGMP Snooping/ proxy
• Virtual LAN (VLAN)
• Quality of Service (QoS)
Wireless LAN
• Compliant with IEEE 802.11n, 802.11g and 802.11b standards
• 2.4 GHz - 2.484 GHz frequency range
• Up to 300Mbps wireless operation rate
• 64 / 128 bits WEP encryption supported
• WPS (Wi-Fi Protected Setup) for easy setup
• Wireless Security with WPA-PSK / WPA2-PSK support
• WDS repeater function support
Management
• Easy Sign-On (EZSO)
• Web-based GUI for remote and local management
• Upload and download of firmware upgrades and configuration data via web-based GUI
• Embedded Telnet server for local management
• Available Syslog
• Supports DHCP server / relay
• TR-069*2 supports remote management
Hardware Specifications
Physical Interface
• Optical SC-connector with options:
- 100BASE-LX dual fiber single-mode WAN (Tx/Rx1310nm)
- 100BASE-BX single-strand single-mode WAN (Tx1310nm/Rx1550nm)
- 100BASE-FX dual fiber multimode WAN (Tx/Rx1310nm)
- 1000BASE-LX dual fiber single-mode WAN (Tx/Rx1310nm)
- 1000BASE-BX single-strand single-mode WAN (Tx1310nm/Rx1490nm)
• 100/1000BASE Optical SFP Optical convector
• WLAN: 3 x detachable antennae
• Ethernet: 4-port 10/100/1000M auto-crossover (MDI / MDI-X) Switch
• Factory default reset button
• WPS push button
• Power jack
• Power switch
Physical Specifications
• Dimensions: 9.04" x 6.10" x 1.69"(229.5mm x 155mm x 43mm)
Power Requirements
• Input: 12V DC, 1.2A
Operating Environment
• Operating temperature: 0 - 40℃
• Storage temperature: -20 - 70℃
• Humidity: 20 - 95% non-condensing
*Notes:
1. IPTV application may require subscription to IPTV services from a Telco / ISP.
2. Only upon request for Telco / ISP tender projects.
3. Specifications in this datasheet are subject to change without prior notice.
4. Future release
|
