Standards
• IEEE 802.11g/b/n draft 2.0
Interface
• USB rev. 2.0 A-Type
Frequency Band
• 2.400GHz ~ 2.4835GH
Modulations
• IEEE 802.11g: OFDM (64-QAM, 16-QAM, QPSK, BPSK)
• IEEE 802.11b: DSSS (CCK/DQPSK/DBPSK)
• IEEE802.11n: OFDM (64-QAM,16-QAM,QPSK, BPSK)
Data Rates
• IEEE 802.11g: 54, 48, 36, 18, 12, 9 & 6Mbps; Auto-fallback
• IEEE 802.11b: 11, 5.5, 2 and 1 Mbps; Auto-fallback
• Legacy, Mixed and Green Field Modes, Support 20/40MHz Bandwidth MCS0-7 (150Mbps PHY Rate Support)
Security
• 64/128bit WEP, WPA, WPA2, 802.1x and 802.11i
• Cisco CCX Compliant
Transmitting Power
• 802.11b: up to 16.5 ±1 dBm
• 802.11g: up to 13.5 ±1 dBm
• 802.11n: up to 13.5 ±1 dBm
Antenna
• Integrated diversity antenna
Number of Operational Channels
• U.S. 1-11
• Japan 1-13, 14
• Elsewhere Worldwide 1-13
Supported Operating Systems
• Windows 2000/XP/Vista
• Mac 10.3/10.4
Receiver Sensitivity
• 54Mbps OFDM, 10% PER, -70dBm
• 11Mbps CCK, 8% PER, -85dBm
• 1Mbps BPSK, 8% PER, -91dBm
• 11n MCS15 & MCS7 20MHZ, 10% PER,-64dBm
• 11n MCS15 & MCS7 40MHZ, 10% PER, -61dBm
Dimensions
• 88(L) x 27(W) x11.5(H) mm
Weight
• 19.9g
Temperature Range
• Operation: 0°C ~ 40°C
• Storage: -20°C ~ 80°C
Humidity
• Operating: Max. 95% (Non Condensing)
• Storage: Max. 95% (Non-Condensing)
Certifications
• FCC,CE
|
