ADSL Compliance
• Compliant with ADSL Standard
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
• Compliant with ADSL2 Standard
- G.dmt.bis (ITU G.992.3)
- ADSL2 Annex M (ITU G.992.3 Annex M)
(Available for BiPAC 7402(G)L R3A only)
• Compliant with ADSL2+ Standard
- G.dmt.bisplus (ITU G.992.5)
- ADSL2+ Annex M (ITU G.992.5 Annex M)
(Available for BiPAC 7402(G)L R3A only)
Network Protocols and Features
•NAT, static routing and RIP-1/2
•Universal Plug-and-Play (UPnP) Compliant
•Dynamic Domain Name System (DDNS)
•Virtual Server and DMZ
•SNTP, DNS relay, IGMP Proxy
•POP3 (email account checking)
•IGMP Snooping for video service
Firewall
•Built-in NAT firewall
•Stateful Packet Inspection (SPI)
•Prevents DoS attacks including IP spoofing, land attack, Smurf attack, ping-of-death, TCP SYN flooding etc.
•Packet Filtering - port, source IP address, destination IP address,MAC address
•URL Content Filtering - string or domain name detection in URLstring
Quality of Service Control
•Supports the DiffServ approach
•Traffic prioritization and bandwidth management based-onIP protocol, port number and address
ATM and PPP Protocols
•ATM Adaptation Layer Type 5 (AAL5)
•Multiple protocols over AAL5 (RFC 2684, formerly RFC 1483)
•Bridged or routed Ethernet encapsulation
•VC and LLC based multiplexing
•PPP over Ethernet (PPPoE)
•PPP over ATM (RFC 2364)
•Classical IP over ATM (RFC 1577)
•MAC Encapsulated Routing (RFC 1483 MER)
•OAM F4/F5
Management
•Quick Installation Wizard and auto-scan ADSL settings
•Web-based GUI for remote and local management
•Firmware upgrade and configuration data upload and download via web-based GUI
•Embedded Telnet server for remote and local management
•Available Syslog monitoring
•SNMP v3, MIB-I and MIB-II support
•Supports DHCP server/client/relay
•TR-069*3 supports remote management
IPTV Applications*2
• IGMP Snooping
• Virtual LAN (VLAN)
• Quality of Service (QoS)
Wireless 802.11g
• Compliant with IEEE 802.11g and 802.11b standards
• 2.4 GHz - 2.484 GHz frequency range
• Up to 54 Mbps wireless operation rate
• WPS (Wi-Fi Protected Setup) for easy setup
• 64-/128-bit WEP supported for encryption
• Wireless security with WPA-PSK/WPA2-PSK support
• WDS repeater function support Physical Interface
Hardware Specification
Physical Interface
• WLAN: one 2 dBi detachable antenna and one internal, printed antenna
• WAN: ADSL port
• LAN: 4-port 10/100 Mbps auto-crossover (MDI/MDI-X) Switch
• Console: the Ethernet Port # 4 can be also connected to console
• Optional USB 2.0 host
• WPS push button
• Power jack
• Power switch
Physical Specification
• Dimensions: 7.09" x 4.72" x 1.57" (180 mm x 120 mm x 40 mm)
Power Requirement
• Input: 12 V DC, 1 A
Models & Standards Support
• BiPAC 7402(G)L R3A: Annex A and Annex M
• BiPAC 7402(G)L R3U: U-R2 and Annex B
• Annex A and Annex M: ADSL over POTS
• Annex B and Annex U-R2: ADSL over ISDN
Operating Environment
• Operating temperature: 0 ~ 40ºC
• Storage temperature: -20 ~ 70ºC
• Humidity: 20 ~ 95% non-condensing |
